Product Details
Place of Origin: Shenzhen, China
Brand Name: MQ
Certification: ISO 9241; IEC62341; JEITA CP-3451; ANSI/AAMI ES60601-1-2; IEC 60068
Model Number: ZY-12301-B01
Payment & Shipping Terms
Minimum Order Quantity: 1 piece
Price: Please contact us for latest price
Packaging Details: Customized
Delivery Time: 1~7 working days
Payment Terms: T/T, L/C, Credit card, PayPal
Supply Ability: 500,0 pieces per day
Size (inch): |
12.3 |
Resolution: |
1920(RGB)×720 |
Active Area (W*H): |
292.032(H) X109.512(V) |
Outline Dimension (W*H*T): |
324.18(W)×139.21(H) ×13.26(D） |
Viewing Angle(RLUD): |
IPS |
Operating Temperature: |
‐30 °C ~ 75 °C |
Size (inch): |
12.3 |
Resolution: |
1920(RGB)×720 |
Active Area (W*H): |
292.032(H) X109.512(V) |
Outline Dimension (W*H*T): |
324.18(W)×139.21(H) ×13.26(D） |
Viewing Angle(RLUD): |
IPS |
Operating Temperature: |
‐30 °C ~ 75 °C |
12.3 inch Product Technical Parameters
| Display Parameters | |||||
| Item | Unit | Specification | Item | Unit | Specification |
| Screen Size | inch | 12.3” (Diagonal) | Viewing Angle | deg. | IPS |
| Display Resolution | dot | 1920(RGB)×720 | Contrast ratio | - | 1200 |
| Active Area | mm | 292.032×109.512 | Operating Temperature | - | ‐30 °C ~ 75 °C |
| Overall Dimension | mm | 324.18×139.21×13.26 | Storage Temperature | - | ‐30 °C ~ 85 °C |
| Power Supply Voltage | V | 3.3 | Weight | g | 510±51g |
| Interface | - | LVDS 70 | Luminance | cd/㎡ | 930 |
Product description
C123HAN02.2: 12.3" AHVA TFT-LCD Display - A Visual Marvel
The C123HAN02.2 presents a high-performance 12.3" TFT-LCD display that flaunts AHVA (Advanced Hyper-Viewing Angle) technology and is crafted with LTPS (Low Temperature Poly-Si). This display module is a sophisticated ensemble comprising a TFT-LCD panel, driver ICs, FPCA, and a TCON (timing controller).
Key Features
The C123HAN02.2 is truly an ideal solution for applications that demand high-quality visuals, reliable performance, and wide viewing angles. Whether it's for automotive displays, industrial control panels, or digital signage, this display is sure to captivate and impress.
FAQ:
Do you have HDMI Board?
Yes, we have HDMI board, and drive board to support android system.
Do you have Touch screen?
Yes, Capacitive touch screen and Resistive touch screen can be customized
Do you support small batch orders?
Yes, we accept small batch trial orders.
How about your after-sale service?
The warranty period is 12 months, calculated from the delivery date. Any failure due to quality reason, our company will provide free maintenance service or replacement if necessary.
