Product Details
Place of Origin: Shenzhen, China
Brand Name: MQ
Certification: ISO 9241; IEC62341; JEITA CP-3451; ANSI/AAMI ES60601-1-2; IEC 60068
Model Number: 92-09002-HH1
Payment & Shipping Terms
Minimum Order Quantity: 1 piece
Price: Please contact us for latest price
Packaging Details: Customized
Delivery Time: 1~7 working days
Payment Terms: T/T, L/C, Credit card, PayPal
Supply Ability: 500,0 pieces per day
Size (inch): |
9.0 |
Resolution: |
1024x600 |
Active Area (W*H): |
196.608(W)x114.15(H) |
Outline Dimension (W*H*T): |
210.7(W)x124.6(H)X5(T) |
Viewing Angle(RLUD): |
IPS |
Operating Temperature: |
-30℃~80℃ |
Size (inch): |
9.0 |
Resolution: |
1024x600 |
Active Area (W*H): |
196.608(W)x114.15(H) |
Outline Dimension (W*H*T): |
210.7(W)x124.6(H)X5(T) |
Viewing Angle(RLUD): |
IPS |
Operating Temperature: |
-30℃~80℃ |
Product Technical Parameters
| Diagonal Size | 9” | Touch Panel Optional | Yes |
| Display Format | 1024x600 Pixels | Contrast Ratio(Typ) | 800 |
| Interface | HDMI | Viewing Direction | ALL |
| IC or Equivalent | - | Viewing Angle Range | Left:85 , Right:85 , Up:85 , Down:85 degree |
| Connection | Plug-in FPC | Brightness(Typ) | 500 cd/m2 |
| Outline Dimension | 210.7(W)x124.6(H)X5(T)mm | Operating Temperature | -30℃~80℃ |
| Active Area | 196.608(W)x114.15(H)mm | Storage Temperature | -30℃~80℃ |
Product description
The 90-07027-IH1 is a highly versatile 7" HDMI LCD Panel.
The 90-09002-HH1 is a highly adaptable 9" LCD Screen. It has a resolution of 1024x600 pixels and comes with a HDMI/VGA signal driver board. There's optional touch panel support available, such as a 4-wire resistive touch panel with a USB driver board and cable, or a capacitive touch panel with a USB controller board and cable.
This display is engineered for excellent image quality, providing full viewing angles. It's a great option for numerous applications including embedded systems, automotive displays, industrial equipment, security systems, and handheld devices where high-quality video output is crucial. Its compatibility with Raspberry Pi via HDMI boosts its flexibility, working well with operating systems like Raspbian, Ubuntu, and Windows 10 IoT. Moreover, it supports multi-touch and is driver-free, facilitating easy integration.
In addition to its use with Raspberry Pi, the 90-07017-BH1 can function as a computer display, being compatible with Windows 11, 10, 8, and 7. Its driver-free feature and multi-touch capabilities make it a handy display solution suitable for a wide range of applications.
FAQ:
Do you have HDMI Board?
Yes, we have HDMI board, and drive board to support android system.
Do you have Touch screen?
Yes, Capacitive touch screen and Resistive touch screen can be customized
Do you support small batch orders?
Yes, we accept small batch trial orders.
How about your after-sale service?
The warranty period is 12 months, calculated from the delivery date. Any failure due to quality reason, our company will provide free maintenance service or replacement if necessary.
