Product Details
Place of Origin: Shenzhen, China
Brand Name: MQ
Certification: ISO 9241; IEC62341; JEITA CP-3451; ANSI/AAMI ES60601-1-2; IEC 60068
Model Number: 44-07012-BH1
Payment & Shipping Terms
Minimum Order Quantity: 1 piece
Price: Please contact us for latest price
Packaging Details: Customized
Delivery Time: 1~7 working days
Payment Terms: T/T, L/C, Credit card, PayPal
Supply Ability: 500,0 pieces per day
Size (inch): |
7.0 |
Resolution: |
800(RGB)× 480 |
Active Area (W*H): |
90( (H) X62(V) |
Outline Dimension (W*H*T): |
90(H) X62(V) |
Viewing Angle(RLUD): |
IPS |
Operating Temperature: |
-10℃～+60℃ |
Size (inch): |
7.0 |
Resolution: |
800(RGB)× 480 |
Active Area (W*H): |
90( (H) X62(V) |
Outline Dimension (W*H*T): |
90(H) X62(V) |
Viewing Angle(RLUD): |
IPS |
Operating Temperature: |
-10℃～+60℃ |
Product Technical Parameters
| Definition | Description | Definition | Description |
| GND | - | G+ | Green Signal+ |
| VS | Field sync signal | GND | +Ground |
| HS | Line sync signal | B+ | Blue signal+ |
| GND | - | GND | Ground |
| R+ | Red signal | NC | - |
| GND | Ground | NC | - |
Product description
1.Scope of Application
The models AT043TN24 V.1 and AT043TN25 V.2, along with AT050TN43 V.1, are applicable for assembling 4.3-inch and 5-inch LCD displays with resolutions of 480272 and 800480 respectively.
Product Function Description
Signal Input Options: It provides VGA and optionally CVBS1 and CVBS2 video signal input.
Power Specification: Accepts power input of DC +12V.
OSD Functionality: Offers multi-function OSD operation.
Optional Remote Control: Comes with an IR infrared remote control function as an optional feature.
2.Signal Input Standard
CVBS: Has a specification of 1.0Vp-p75Ω.
VGA: Operates at resolutions of 480272 and 800480 with a refresh rate of 60 to 70HZ.
3.Working Environment
Temperature Range: The working temperature is between -10℃ and +60℃.
Humidity Condition: The working humidity is 90%RH with no condensation.
Driver Board Power Consumption Details (For AT043TN24 V.1 at Ta = 25℃).
FAQ:
Do you have HDMI Board?
Yes, we have HDMI board, and drive board to support android system.
Do you have Touch screen?
Yes, Capacitive touch screen and Resistive touch screen can be customized
Do you support small batch orders?
Yes, we accept small batch trial orders.
How about your after-sale service?
The warranty period is 12 months, calculated from the delivery date. Any failure due to quality reason, our company will provide free maintenance service or replacement if necessary.
